Model No.: NK-LDSI-P10

RGB LED Display Screen, Indoor Full Color P10
1. Energy Saving
2. High gray scales, vividly color
3.Superior color uniformity

Product Description

1. Energy Saving
2. High gray scales, vividly color
3. High refresh rate without water wave
4. Superior color uniformity
5. Brightess adjustable
6. Spot-spot correction is optional
7. Long life LED chips and material choice
8. HIgh cost performace with wholesale price

Indoor P10 RGB Display Parameter
To get best white balance, color ratio is designed to be R: G: B/3: 6: 1.
Pixel	Item	Parameter
	Real Pixel pitch	10mm
	Pixel composition	1 red, 1 green and 1 blue LED inside SMD
Module	Module resolution	32x16 =512pixels
	Module size	320MM x160MM
Cabinet	Cabinet size	960MM x960MM x 100MM
	Cabinet resolution	Real pixel: 9216pixels
	Cabinet materials	Cold rolled steel (mixed Iron & steel)
Screen	Physical Resolution /sqm	10000pixels/sqm
	Brightness	MAX: 3000cd/sqm
	Brightness adjustment	256 level automatically
	Scanning method	Static & 1/2 scan pixel
	Drive methods	Constant current drive
	Best Viewing angle	Horizontal: 120 degrees, vertical: 90 degrees,
	Grey scale	16384 levels
	Color processing	14bit
	Display colors	440billion
	Contrast ratio	2000: 1
	Frame rate	> 60 frames/sec
	Refresh rate	300-3000HZ(no flickers while camcorder recording)
	Control method	Synchronized with computer monitor
	Lifetime	> 100, 000 hours
	Defects rate	≤ 0.0001
	Operating voltage	AC220V± 15% 50/60HZ
	Screen power consumption	Max: 1125w/sqm; Average: 600w/sqm
	Color temperature	6500K± 500
	Control distance.	100 m(no repeating) by net line; Optical fiber: 500m- 10km
	IP level	IP33 both in the front and back
	Operating temperature	— 20degree--+60degree
	Operating ambient humidity	10%— 95%RH
